Oil Mist Collector-H Series(JW-1000-H)
JW-1000-H
JW-1000-H Coolant Mist Collector can connect to your machine tool to collect and purify oil mist, and the coolant mist separator efficiency reaches over 99.9%. The collected oil mist does not need to be further filtered and can be reused directly.
This coolant mist collection method is popular in the factory. Juwei has provided Dmg Mori, Mazak, Makino, etc, well-known CNC machine leading brands with coolant collection solutions. Our coolant mist collector can also be retrofitted based on customers' requirements and customized options as required.
Juwei Coolant Mist Collectors Advantage
- Easy to install, maintain and use.
- Clean up much exhaust and mist in the air efficiently.
- The service life is very long and reduces costs.
- Can be installed on all kinds of machines that produce oil mist
- High quality at a competitive price point.
Item | Unit | Specification |
---|---|---|
HP | HP | 1/4HP 0.18KW |
Air flow | m3/min | 16 |
Air intake diameter | m/m | 150 |
Voltage | V | 220/380 |
Electric cuttent | A | 1/0.66 |
Cycle | HZ | 50/60 |
Speed | R.P.M | 2850/3500 |
Noise | db | 62 |
Weight | kg | 35 |
Length | mm | 620 |
Width | mm | 340 |
Height | mm | 495 |

Item | Size |
---|---|
Length | 620 |
Width | 340 |
Height | 495 |
-
Stainless Net
-
PVC Tube Hose
-
Wire
-
PVC Flexible Duct Hose
-
Hose Clamp
-
Rubber Feet
-
Flange
-
Motor Starter
-
Adjustable Hose
-
Ozone Machine
-
Adjustable Stand
Item | Unit | Specification |
---|---|---|
HP | HP | 1/4HP 0.18KW |
Air flow | m3/min | 16 |
Air intake diameter | m/m | 150 |
Voltage | V | 220/380 |
Electric cuttent | A | 1/0.66 |
Cycle | HZ | 50/60 |
Speed | R.P.M | 2850/3500 |
Noise | db | 62 |
Weight | kg | 35 |
Length | mm | 620 |
Width | mm | 340 |
Height | mm | 495 |
